BULKHEAD EMERGENCY LIGHT
Specification
- Model: FG-T603L
- Voltage 85-265VAC 50/60Hz
- AC Power 2W Battery Ni-MH - SC 4.8V / 2200MAH
- Emergency Duration> 3Hours
- LED 20 pcs SMD2835
- Lumen >250LM Color White
BULKHEAD EMERGENCY LIGHT
Specification
- Model: FG-T605L
- Voltage 85-265VAC 50/60Hz
- AC Power 2W Battery Ni-MH - SC 4.8V / 2200MAH
- Emergency Duration > 3Hours
- LED 1 pc SMD 3W Lumen >310LM
- Color White
GROOVED BUTTERFLY VALVE 25GG-200, 25GG-250 & 25GG-300
FM Approved grooved end butterfly valve with integrated signal gear box, conforming to FM1112 test standards with fusion bonded coating. Featuring factory-installed double tamper switches suitable for both indoor and outdoor use, the 25GG provides reliable supervisory monitoring for fire protection system integration.
Available in three pressure ratings and sizes from 50mm (2") to 300mm (12"), with grooved end connections conforming to AWWA C606 and VDS 2100 standards, making it well suited to fully grooved fire protection pipework systems.
Key Specs:
- Models: 25GG-200 | 25GG-250 | 25GG-300
- Working Pressure: 200 / 250 / 300 PSI
- Working Temperature: -10°C to 120°C
- Valve Standard: FM1112 | Coating: FM1112
- Face-to-Face Standard: MSS-SP67 Long
- Grooved Ends: AWWA C606 / VDS 2100
- Sizes: 50mm to 300mm (2" to 12")
- Approval: FM Approved
Materials:
| Part | Material |
|---|---|
| Body | Ductile Iron (ASTM A536) |
| Disc | Ductile Iron EPDM Coated (ASTM A536+EPDM) |
| Upper & Lower Stems | Stainless Steel (AISI 410) |
| O-Ring | EPDM |
| Bushing | Bronze (ASTM B150M C63000) |
| Gear Box Housing | Ductile Iron (ASTM A536) |
| Gland/Washer/Plug | Galvanised Carbon Steel, Surface Passivation |
Factory-installed double tamper switches for indoor and outdoor use — suitable for grooved fire protection pipework systems requiring supervisory monitoring.
WAFER BUTTERFLY VALVE 25W-300, 25W-250 & 25W-200
FM Approved wafer style butterfly valve with integrated signal gear box, conforming to FM1112 test standards with fusion bonded coating. The slim wafer body fits between standard flanges for a compact, lightweight installation, while the signal gear box provides supervisory switching for fire alarm control panel integration.
The wafer counterpart to the lugged FGBL-300, available in three pressure ratings and sizes from 50mm (2") to 300mm (12"), compatible with BS EN, ASME, and Class 150 flange standards.
Key Specs:
- Models: 25W-200 | 25W-250 | 25W-300
- Working Pressure: 200 / 250 / 300 PSI
- Working Temperature: -10°C to 120°C
- Valve Standard: FM1112 | Coating: FM1112
- Face-to-Face Standard: ISO5752
- Flanged Ends: BS EN1092-2 / ASME B16.42 / Class 150
- Sizes: 50mm to 300mm (2" to 12")
- Approval: FM Approved
Materials:
| Part | Material |
|---|---|
| Body | Ductile Iron (ASTM A536) |
| Disc | Ductile Iron EPDM Coated (ASTM A536+EPDM) |
| Upper & Lower Stems | Stainless Steel (AISI 410) |
| O-Ring | EPDM |
| Bushing | Bronze (ASTM B150M C63000) |
| Gear Box Housing | Ductile Iron (ASTM A536) |
| Gland/Washer/Plug | Galvanised Carbon Steel, Surface Passivation |
Wafer body design for compact between-flange installation — the space-saving alternative to the lugged FGBL-300 where dead-end service is not required.
BUTTERFLY VALVE FGBVG20 (Ductile Iron Body) FGBVG22 (Bronze Body)
FM Approved and UL Listed resilient seated butterfly valve with groove ends, featuring a fusion bonded coating complying with AWWA C550. Available in ductile iron (FGBVG20) or bronze (FGBVG22) body construction, and supplied with factory-installed UL Listed double tamper switches suitable for both indoor and outdoor use, the FGBVG20/22 provides reliable shutoff and supervisory monitoring for fire protection system integration.
Available in sizes from 50mm (2") to 65mm (2½"), with groove end connections conforming to AWWA C606, making it well suited to grooved fire protection pipework systems.
Key Specs:
- Models: FGBVG20 (Ductile Iron) | FGBVG22 (Bronze)
- Working Pressure: 175 PSI
- Working Temperature: -20°C to 110°C
- Coating Standard: AWWA C550
- Groove Ends: AWWA C606
- Sizes: 50mm to 65mm (2" to 2½")
- Approvals: UL Listed & FM Approved
Materials:
| Part | Material |
|---|---|
| Body (FGBVG20) | Ductile Iron (ASTM A536 65-45-12) |
| Body (FGBVG22) | Bronze (ASTM B62 C83600) |
| Disc | Steel + EPDM (ASTM 1045 + EPDM) |
| Upper & Lower Shaft | Stainless Steel (SS630) |
| O-Ring | EPDM |
| Gasket | Stainless Steel (AISI 304) |
Factory-installed UL Listed double tamper switches for indoor and outdoor use — suitable for grooved fire protection pipework systems requiring supervisory monitoring.
BUTTERFLY VALVE FGBVT20 (Ductile Iron Body) FGBVT22 (Bronze Body)
FM Approved and UL Listed resilient seated valve with screwed ends, featuring a fusion bonded coating complying with AWWA C550. Available in ductile iron (FGBVT20) or bronze (FGBVT22) body construction, and supplied with factory-installed UL Listed double tamper switches suitable for both indoor and outdoor use, the FGBVT20/22 provides reliable shutoff and supervisory monitoring for fire protection system integration.
Available in sizes from 25mm (1") to 65mm (2½"), with screwed end connections conforming to ASME B1.20.3 NPT and EN10226-1 Rp, making it well suited to threaded fire protection pipework systems.
Key Specs:
- Models: FGBVT20 (Ductile Iron) | FGBVT22 (Bronze)
- Working Pressure: 175 PSI
- Working Temperature: 20°C to 110°C
- Coating Standard: AWWA C550
- Screwed Ends: ASME B1.20.3 NPT / EN10226-1 Rp
- Sizes: 25mm to 65mm (1" to 2½")
- Approvals: UL Listed & FM Approved
Materials:
| Part | Material |
|---|---|
| Body (FGBVT20) | Ductile Iron (ASTM A536 65-45-12) |
| Body (FGBVT22) | Bronze (ASTM B62 C83600) |
| Disc | Steel + EPDM (ASTM 1045 + EPDM) |
| Upper & Lower Shaft | Stainless Steel (SS630) |
| O-Ring | EPDM |
| Gasket | Stainless Steel (AISI 304) |
Factory-installed UL Listed double tamper switches for indoor and outdoor use — suitable for threaded fire protection pipework systems requiring supervisory monitoring.
CO DETECTORS
The FG731 is a stand-alone carbon monoxide detector powered by long-life internal batteries, providing up to 5 years of continuous protection without the need for wiring or connection to a fire alarm control panel. Featuring a Japan-made electrochemical CO sensor with automatic adjustment and advanced detection algorithms, it delivers highly accurate CO detection with strong immunity against nuisance alarms.
Smart Detection, Clear Indication Three separate LED indicators provide instant status clarity — green for power, red for alarm, and yellow for service required. When CO levels reach dangerous thresholds, the internal 85 dB sounder activates to alert occupants. A dual-function button allows temporary alarm silencing (Hush mode) during suspected false alarm conditions, and doubles as a test button to verify correct operation.
Tiered Alarm Response The FG731 responds proportionally to CO concentration levels, triggering alarms progressively based on exposure time and concentration — from 70 ppm over 60–240 minutes through to 400 ppm within just 4–15 minutes — in line with recognised CO safety standards.
Hassle-Free Ownership No programming is required for installation. A built-in 5-year end-of-life timer audibly alerts the owner when the unit is due for replacement, and a low battery audible indication ensures the detector is never left unprotected.
Key Specifications
- Operating Voltage: DC 4.5V (3 × AA batteries)
- Sensing Cell: Electrochemical
- Alarm Thresholds: 70 ppm (60–240 min) / 150 ppm (10–50 min) / 400 ppm (4–15 min)
- Sounder Output: ≥85 dB @ 3m
- Operating Temperature: +4.4°C to +37.8°C
- Operating Humidity: 15–90% RH (non-condensing)
- Dimensions: 64 × 112 × 44mm
CONSEALED SPRINKLER
Model No. FA019 & FA020
UL Listed concealed pendant automatic glass bulb fire sprinklers featuring a 5.6 K-factor with flat plate concealed design for discreet ceiling installations. Model FA019 offers Standard Response with a 5mm glass bulb, while Model FA020 provides Quick Response with a 3mm glass bulb for faster activation in fire emergencies. Suitable for standard coverage applications in commercial and residential settings.
Product Overview
The Series FA019 and FA020 fire sprinklers are designed for discreet ceiling installations and are activated when exposed to heat from a fire. The sprinkler's soldered cover plate detaches at its rated temperature, exposing the glass bulb to heat. As the bulb heats, internal fluid expands and compresses the air bubble within. Once maximum compression is reached, the pressure breaks the glass bulb, triggering water discharge to suppress the fire.
Key Features
- Model FA019: Standard Response sprinkler with 5mm glass bulb
- Model FA020: Quick Response sprinkler with 3mm glass bulb for faster activation
- Flat plate concealed design for aesthetic ceiling integration
- UL Listed for both models
- Multiple temperature ratings and cover plate finishes available
Technical Specifications
|
Feature |
FA019 |
FA020 |
|---|---|---|
|
SIN |
FA019 |
FA020 |
|
Style |
Concealed Pendent |
Concealed Pendent |
|
K Factor |
5.6 (80 metric) |
5.6 (80 metric) |
|
Flow Rategpm/(psi)½(L³/min(bar)½) |
5.6 (80 metric) |
5.6 (80 metric) |
|
Nominal Pressure |
1/2" NPT OR 1-2" BSPT |
1/2" NPT OR 1-2" BSPT |
|
Max. Working Pressure |
175 PSI (12BAR) |
175 PSI (12BAR) |
|
Response |
STANDARD |
QUICK |
|
Factory Test Pressure |
500 PSI (35BAR) |
500 PSI (35BAR) |
|
Min. Operating Pressure |
7 PSI(0.5 BAR) |
7 PSI(0.5 BAR) |
|
Cover Plate Finishes |
White Coating, Chrome, Bright Brass, Brass & Custom |
White Coating, Chrome, Bright Brass, Brass & Custom |
Sprinkler Material Components
|
Part |
Material |
|---|---|
|
Load Screw |
DZR Brass |
|
Bulb Seat |
Brass |
|
Frame |
DZR Brass |
|
Seal |
Beryllium Nickel w/Teflon |
|
Deflector |
Bronze |
|
Support Cup |
Steel |
|
Guide Pins |
Stainless Steel 316 |
|
Cover Plate |
H162 Brass |
|
Skirt |
Brass |
|
Ejection Spring |
C5191 |
Temperature Ratings
|
SIN |
K-Factor |
135°F (57°C)Cover Plate |
155°F (68°C)Cover Plate |
165°F (74°C)Cover Plate |
200°F (93°C)Cover Plate |
|---|---|---|---|---|---|
|
|
|
135°F (57°C)Sprinkler |
155°F (68°C)Sprinkler |
175°F (79°C)Sprinkler |
200°F (93°C)Sprinkler |
|
FA019/FA020 |
5.6 |
Y |
Y |
Y |
Y |
- Do not exceed 14 ft-lb torque for 1/2 inch NPT sprinkler threads
- Keep protective cap on until system is placed in service
- Do not wrench any part other than the sprinkler body
- In case of thread leak, remove unit, apply new compound/tape and re-install
CONVENTIONAL PANEL
The FGZ is a reliable and straightforward conventional fire alarm control panel available in 1, 2, and 4-zone configurations — ideal for small to medium-sized buildings requiring a cost-effective, easy-to-operate fire detection and notification solution. Each zone supports up to 50 devices, including smoke detectors, heat detectors, and manual call points.
Intelligent Alarm Confirmation To minimise false alarms, the FGZ provides up to 120 seconds of configurable delay time after an initial alarm signal is received, allowing personnel to verify whether a real fire condition exists before full evacuation is triggered. The panel clearly distinguishes between first fire alarm and subsequent alarm events through detailed status indicators.
Comprehensive Monitoring & Control All input and output devices are continuously monitored by the panel. Zones and sounders can be individually disabled for maintenance, and the panel automatically disconnects any zone or sounder circuit detected as short-circuited. A mains-lost silence mode is also available, preventing nuisance fault signals during planned power interruptions.
Key Specifications
- Main Power: AC220V ±15%, 50Hz / AC110V ±15%, 60Hz
- Zone Voltage: 24V ±2V | Zones: 1, 2, or 4
- Zone Capacity: Up to 50 devices per zone
- End-of-Line Resistors: 3.9KΩ, 1W
- Zone Alarm Current: >20 mA | Short Current: >11 mA
- Sounder Output: 3 groups × 300 mA max / 24VDC
- Auxiliary Supply: 300 mA / 24V
- Battery Backup: 2 × 12V 3.3Ah (24VDC)
- Fault Relay Contacts: Rated 0.5A SELV
- Humidity: ≤95% RH
- Dimensions: 290 × 87.5 × 211.5mm | Weight: 2,100g (without battery)
CORRESPONDING CONTROLLER
It is responsible for information transfer within a certain area, thus increasing the number of subordinate devices and facilitating data.
Specification
- Model: FG-REP01
- Voltage AC120V/0.035A or AC277/0.016A 50/60Hz
- AC Power 3W Battery Ni-MH - AA 600MAH/4.8V
- Emergency 3Hours Duration
- Communication 485 BUS BUS
DEISEL ENGINE
CLARKE fire engines has the world’s largest range of UL/FM approved diesel fire pump drivers. Clarke Fire Engine covers UL /FM pump requirements from 31 kw to 764 kw with operating speeds from 1470 RPM to 3000 RPM All Clarke engines are supplied with a standard 24-month manufacturer’s warranty Clarke Fire engine has innovative and patented Pressure Limited Driver diesel engine which protects the sprinkler system from over pressurization by varying engine RPM Clarke fire engine has dual starting technology as well as the technology for dual ECM electronic injection engines. Both increased diesel engine reliability and performance. Its driveshaft style couplings solved field alignment problems, and significantly reduced the time needed for engine/fire pump installation and maintenance. Clarke has implemented an exciting, ongoing and continuous product improvement program which will provide even more high-quality Clarke engine models to meet and exceed the demands. A deduction of 3% of the power is made for each 1000 feet rise in altitude above 300 feet and 1%for each 10 Degree above 77 Degree ambient temperature. Minimum instrumentation and control including adjustable speed governor, over speed shutdown device set approximate 20 above rated engine speed, tachometer with hour meter, oil pressure gauge and temperature gauge. Most diesel engines models work seamlessly with FIREGUARD fire pumps. Working together, they deliver the most efficient and reliable fire pump solutions. Our integrated diesel pump units make us stand out in the market. Optional: NM Fire Engine, Kirloskar
DELUGE VALVE MODEL C1,N1 & D1
Deluge Valve is an automated system control valve used for the fast application of water in spray systems, protecting areas such as power transformer installations, storage tanks, conveyor protection, and other industrial applications. With the addition of a foaming agent, the Deluge Valve can also be used to protect aircraft hangars and inflammable liquid fires.
The Deluge Valve is a quick-release, hydraulically operated diaphragm valve, featuring three chambers isolated from each other by a diaphragm-operated clapper and seat seal — enabling fast, reliable actuation when the system is triggered.
Key Specs:
- Models: C1 (Cast Steel) | D1 (Ductile Iron) | N1 (Nickel Aluminium Bronze — suitable for sea water applications)
