ATMOSPHERIC FOAM CONCENTRATE STORAGE TANK
The atmospheric foam concentrate storage tank is manufactured in stainless steel material. The tank is
provided with an expansion dome with a volume not less than 2% of the total capacity of the tank. All the
tanks must be kept filled upto the level of half way of expansion dome. A sediment sump is provided at the
bottom of the concentrate tank. The tank is provided with an inlet, an outlet, a drain connection and a fill
connection. The horizontal tanks are supported by two saddles/legs welded to the tank and drilled for anchoring. Tank is provided with lifting lugs, designed to lift empty tanks. The tank has flat ends but can be provided with dished ends if needed.
Atmospheric foam concentrate storage tank is used with Inline Foam Inductor and Inline Balance Pressure
Foam Proportioning system. Refer to data-sheets/ product catalogues of these devices for equipment operational and installation guidelines.
