Wafer Butterfly Valve With Single Gear Box FGBW-300
FM Approved resilient seated non-rising stem (NRS) gate valve with flanged end connections, conforming to AWWA C515 and BS5163 with fusion bonded epoxy coating compliant with AWWA C550. The 300 PSI rated standard size range counterpart to the large-bore FGN909-250, covering 50mm (2″) to 300mm (12″) and compatible with both ANSI and EN flange standards. The compact NRS design makes it suitable for installations where headroom is limited or a rising stem is not practical.
Key Specs:
- Working Pressure: 300 PSI
- Working Temperature: -10°C to 120°C
- Valve Standard: AWWA C515 / BS5163 | Coating: AWWA C550
- Connection Ends: ANSI B16.1 Class 125 / B16.42 Class 150, EN1092-2 PN16
- Sizes: 50mm to 300mm (2″ to 12″)
- Approval: FM Approved
Materials:
| Part | Material |
|---|---|
| Body | Ductile Iron (A536 65-45-12) |
| Wedge Disc | Ductile Iron, EPDM Coated |
| Disc Nut | Bronze (ASTM B62) |
| Stem | Stainless Steel (AISI 304/420) |
| Bonnet | Ductile Iron (A536 65-45-12) |
| Thrust Collar | Bronze (ASTM C51100) |
| Gasket | EPDM |
| Gland | Ductile Iron (A536 65-45-12) |
| Wrench Nut | Ductile Iron (A536 65-45-12) |
Flanged NRS gate valve at 300 PSI in standard pipe sizes — suits space-constrained fire protection installations where a non-rising stem is preferred over an OS&Y design.
